2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100

I'm Online Chat Now
Certification
China Anping Huilong Wire Mesh Manufacture Co., Ltd certification
China Anping Huilong Wire Mesh Manufacture Co., Ltd certification
Not only your good products, but also your good after-sale services impressed me. Hope for more cooperations.

—— Michael

I ordered 3000 rolls of Welded Wire Mesh, and found that 3 rolls were damaged during transportation, but the factory compensated me within 24 hours. Overall, it is recommended.

—— Peter

It's the third time I buy from Huilong. Because of the Cornavirus, price here is very high, so I was looking for it from China. It's a very happy purchasing experience with Huilong, the quality is nothing different with the supermarket, I use the concertina wire for my fence project. The factory gave me gloves and pliers as a gift. It's worth it.

—— Paul

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100
2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100

Large Image :  2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: HUILONG
Certification: CE CERTIFICATE / ISO
Model Number: GBWM-HLLO2305012
Payment & Shipping Terms:
Minimum Order Quantity: 100 SETS
Price: USD12.00-20.00/SET
Packaging Details: IN BUNDLES
Delivery Time: 15 DAYS AS SOON AS WE GET CUSTOMERS L/C OR DEPOSIT.
Payment Terms: T/T, L/C AT SIGHT
Supply Ability: 60 TONS PER DAY
Detailed Product Description
Product Name: Physical Manufacturer 2.7mm/3.4mm 2x1x1 80x100 Mesh Hexagonal Gabion Box Material: Low Carbon Steel Wire,galvanized Steel Wire
Standard: ISO, ASTM A975, EN Finish: Galvanized,PVC Coated
Opening: 60x80, 80x100, 100x120mm Mesh Wire Diameter: 2.2mm, 2.7mm, 3.0mm
Selvedge Wire Diameter: 2.7mm, 3.4mm, 3.9mm Gabion Box Length: 2m Or Customed
Gabion Box Width: 1m Or Customed Gabion Box Height: 1m Or Customed
Packaging: In Bundles Application: For Slope Support, Foundation Pit Support, Mountain Rock Hanging Net With Shotcrete, Slope Planting, Railway And Highway Isolation Block
High Light:

2.7mm Gabion basket wire mesh

,

Hexagonal Gabion basket wire mesh

,

Hexagonal Gabion Mesh 2x1x1

Physical Manufacturer 2.7mm/3.4mm 2x1x1 80x100 Mesh Hexagonal Gabion Box

Gabion basket wire mesh are popular in the worldwide,it widely used in water conservancy, Bridges, road engineering, at the same time to avoid floods, landslides, debris flow and other natural disasters have a significant impact.



Physical Manufacturer 2.7mm/3.4mm 2x1x1 80x100 Mesh Hexagonal Gabion Box produced by Anping Huilong Wire Mesh Manufacture Co.,Ltd are made of high quality low carbon steel wire, then fininshed with galvanize or the green PVC. They are double twisted woven into hexagonal mesh shape. Our factory is certified in compliance with ISO 9001,ASTM and EN.Except the mesh 80x100,the  60x80 100x120 are the normal mesh size we produce,if you have any speical requirements we can customized.

Make you satisfied with our forever pursuit.

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 0

SPECIFICATIONS

Standard ASTM 975 Standards:
style 1 Galvanized wire as per ASTM A 641, class 3 soft temperstyle 2 Same as style 1 with extra coating with PVC.style 3 Zn-5Al or Zn-10Al coated wire as per ASTM A 856, also known as Galfan wire.
EN 10223-3 standard:
Galvanized wire meets EN 10244-2 and old BS 443Wire tensile strength is between 380N/mm2 and 550N/mm2 as per BS 1052.
Mesh size(mm) Wire Diameter(mm) Selvedge wire(mm) Gabion box Size(m) Material
60x80mm 2.2mm/2.7mm 2.4mm/3.4mm 6x2x0.3m/2x1x0.5m 1.galvanized steel wire
80x100mm 2.7mm/3.0mm/3.2mm 2.4mm/3.4mm 2x1x1/3x1x1m/4x1x1m 2.high zinc steel wire
100x120mm 3.0mm/3.05mm/3.2mm 3.4mm 3x1x1/4x1x1m/5x1x1m 3.pvc coated steel wire


GABION BASKET MATERIALS

1) Heavy Galvanized steel wire: Excellent low-carbon steel wire, diameter: 2.0mm-4.0mm, tensile strength: no less than 380Mpa. The surface adopts hot galvanization for protection. The depth of the protective galvanized layer (max. 300g/m2) is decided according to customer's demands.



2) Zinc-5% aluminum-mixed alloy steel wire: (also called galfan steel) a new kind of material appearing recently with corrosion resistance 3 times of traditional pure galvanization; diameter: 2.0mm-4.0mm; tensile strength: no less than 380Mpa.



3) Galvanized steel wire with plastic coating: Excellent low-carbon steel with PVC or PE protective coating on the surface which will be weaved into various gabions. This protective coating will greatly increase the protection in high pollution environment. In addition, the options of different colors enable it merge into the surrounding environment.



4) Zinc-5% aluminum-mixed alloy steel wire with PVC coating: alloy steel wire with PVC or PE protective coating on the surface which will be weaved into various gabions. This protective coating will greatly increase the protection in high pollution environment. In addition, the options of different colors enable it to merge into the surrounding environment.



POPULAR SIZES YOU CAN CHOOSE

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 1

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 2



MASS PRODUCTION PROCEDURE



Wire Material Preparation---Machine weaving---Lacing wire installation---Packaging into bundles---Container loading



2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 3



PACKAGING DETAILS

Gabion Basket is usually packaged in bundles. According to the specific sizes, Gabion Baskets are woven by machines and then will be folded into bundles, fixed with a binding belt, and then loaded into the container. The advantage of doing so is to save container space, so that it achieves the maximum utilization rate. When using, the bundles can be folded, with binding wire to assemble it and stones to fill in it, forming a complete Gabion Basket. It is strong and durable and easy to install, which plays an important role in resisting floods and making dams strong.

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 4



APPLICATIONS

Control and guide rivers and flood DAMS, rock protection, water and soil erosion prevention, bridge protection fixed structures, sea defence works, harbour works, retaining walls, road protection

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 5



OUR SERVICES

  •  As a 18-year factory and we have registered trading company for sourcing more valuable products for the customers. Therefore, we have both the advantages of factory and trading company. We have our own factory, so we can control the product quality timely and efficiently. At the same time, we also have a professional international trade team, providing good and professional services for customers.
  •  We have established the Department of Quality Assurance, every steps from raw material preparation to final product, we have strict quality inspection system to ensure the products meet international standards and satisfy customers. We resolutely put an end to unqualified products flowing into the market. At the same time, we will provide necessary follow-up service assurance. Any problems arising from the cooperation shall be answered within 24 hours and solved within 72 hours.
  •  Free samples are available.
  • Specifications can be customized as per your request.



HUILONG HISTORY

  • In 1989, HUILONG company was established, the original store was located in Anping Wire Mesh World Supermarket;
  • In 1994, Anping HUILONG wire mesh factory was founded, located in Nanhuan East Road, mainly for the domestic market and produce Welded Wire Mesh Roll, Welded Wire Mesh Panel, and Wire Mesh Fence, etc.;
  • In 1998, ethnic Chinese from Philippines visited us and confirmed the intention of cooperation;
  • In 2004, Philippines invested 1 million funds, HUILONG Wire Mesh became a joint venture company named as "ANPING HUILONG WIRE MESH MANUFACTURE CO., LTD.";
  • In 2008, HUILONG wire mesh international sales department successfully obtained European market, establishing a European trading circle based on France, Belgium and Italy;
  • In 2009, we obtained 50 acres land in Taicheng industry park, and built up a brandnew factory. The workshop occupies 25,000㎡, warehouse 10000㎡, with total 300 sales representatives and workers;
  • In 2011, our company exported to more than one hundred countries, cooperated with more than 200 customers;
  • In May 2012, Shijiazhuang international trade branch office was set up;
  • In 2013, we purchased 300㎡ of office building in Shijiazhuang;
  • In 2015, Anping HUILONG Wire Mesh Manufacture Co., Ltd joined the Anping Wire Mesh Chamber of Commerce, becoming an important part of it;
  • In 2016, we set up a new foreign trade team of 35 people, with an office area of 300 square meters;
  • In 2017-2018, our wire mesh products were well sold and well recognized in the markets of America, Africa and Southeast Asia;
  • In 2019, we registered AIBUER TRADING CO., LTD. and integrated more factory resources, enriched product categories, to provide customers with more valuable services;
  • In 2020, HUILONG invested and established Concertina Razor Wire Factory, which covers an area of 7,000 square meters;
  • In 2021, the factory department has established a domestic trade team of 30 people, with a new office area of 600 square meters.

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 6

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 7

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 8

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 9

2.7mm / 3.4mm Hexagonal Gabion Basket Wire Mesh 2x1x1 80x100 10
