14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire

14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire
14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire

Large Image :  14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: HUILONG
Certification: CE CERTIFICATE / ISO
Model Number: GBW-HL003
Payment & Shipping Terms:
Minimum Order Quantity: 50 COILS
Price: USD7.00--USD10.00/COIL
Packaging Details: WOODEN PALLET PACKING, OR BULK PACKING.
Delivery Time: 7 DAYS AS SOON AS WE GET CUSTOMER’S DEPOSIT OR L/C.
Payment Terms: T/T, L/C AT SIGHT
Supply Ability: 50 TONS PER DAY
Detailed Product Description
Features: Beautiful Appearance, High Tensile Strength, Add More Security, Etc. Product Name: High Tensile Flexible Galvanised Barbed Wire Barbed Tape Fence For Modern Security
Material: Galvanized Iron Wire; PVC Coated Iron Wire In Green, Blue, Gray And Any Other Colors Wire Diameter: 14 Gauge
Barb Length: 1.5-3cm Barb Spacing: 7.5-15cm
Zinc Coating: 30-200g/sqm Waeving Type: Normal Twist, Reverse Twist
Coil Length: 100m, 150m, 200m, 250m, 500m, Etc. Coil Weight: 8kg, 10kg, 15kg, 20kg, 25kg/coil
Color: Silver/Galvanized, Dark Green, Gray, Or As Per Your Request Packaging: In Bulk; On Wooden Pallet
High Light:

14 Gauge Galvanized Barbed Wire

,

14 Gauge Concertina Razor Wire

,

Flexible Concertina Razor Wire

High Tensile Flexible Galvanised Barbed Wire Barbed Tape Fence for Modern Security

Barbed Wire is a kind of modern security fencing materials. Barbed Wire can be installed as deterrent to the perimeter intruders with piecing and cutting razor blades mounted at the top of the wall. Galvanized Barbed Wire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts.



Application: Barbed Wire can be widely used as accessories for woven wires fences to form a fencing system or security system. It is called barbed wire fences or barbed obstacles when it is used simply by itself along the wall or the building to give a kind of protection. Barbed Wire is also written as barbed tape as it is always used in a line to form a kind of tape.



SPECIFICATIONS

GALVANIZED BARBED WIRE

Line Wire and Barb Wire Diameter

(BWG)

Approximate Length per Kilogram in meter
Barbs Spacing 3'' Barbs Spacing 4'' Barbs Spacing 5'' Barbs Spacing 6''
12 x 12 6.0617 6.7590 7.2700 7.6376
12 x 14 7.3335 7.9051 8.3015 8.5741
12.5 x 12.5 6.9223 7.7190 8.3022 8.7221
12.5 x 14 8.1096 8.8140 9.2242 9.5620
13 x 13 7.9808 8.8990 9.5721 10.0553
13 x 14 8.8448 9.6899 10.2923 10.7146
13.5 x 14 9.6079 10.6134 11.4705 11.8553
14 x 14 10.4569 11.6590 12.5423 13.1752
14.5 x 14.5 11.9875 13.3671 14.3781 15.1034
15 x 15 13.8927 15.4942 16.6666 17.5070
15.5 x 15.5 15.3491 17.1144 18.4060 19.3386



FEATURES

 High security

 Long service life

 Good rust-resistance ability

 Anti-climbing and anti-theft



MASS PRODUCTION PROCEDURE

Producing Galvanized Barbed Wire is relatively simple. It is produced by an automatic machine, through which the line wire and the barb wire are twisted together and then rolled into a coil. See the pictures below. The speed of the machine is fast, so the production capacity is also excellent.

1) Raw Material Preparation----High quality galvanized iron wire

2) Machine Weaving or twisting

3) PVC Coating (Color as per requirements)

4) Packaging

5) Container Loading

14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 0



PACKAGING DETAILS

Barbed Wire is usually made into coils. For container loading, we have bulk loading and wooden pallet loading. Our packaging will ensure the Barbed Wire not being damaged during storage and shipment. According to the customer’s instruction, we will also put the label paper into the packaging. There will be a certain product description on the label paper, representing product specifications, so that you can be clear about the product information. If you have other special requirements, for example your own label, we can also customize the packaging according to your requirements. In a word, if you have any requirements, please come forward and we will give you the best solution.

14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 1



APPLICATIONS

Galvanized Barbed Wire is widely used for the separation and protection of the boundary of grassland, railway, highway, prison, private field, etc. It can also be used on the top of other types of fences, such as Chain Link Fence, Welded Wire Mesh Fence, Concertina Barbed Wire, etc., to add security in your private property.

14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 2

14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 3



RELATED PRODUCTS

You may also like the following products and accessaries to match your Barbed Wire, and we can also arrange the other goods according to your needs.

14 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 414 Gauge High Tensile Galvanized Barbed Wire , Flexible Concertina Razor Wire 5



OUR SERVICES

  • As a 18-year factory and we have registered trading company for sourcing more valuable products for the customers. Therefore, we have both the advantages of factory and trading company. We have our own factory, so we can control the product quality timely and efficiently. At the same time, we also have a professional international trade team, providing good and professional services for customers.
  • We have established the Department of Quality Assurance, every steps from raw material preparation to final product, we have strict quality inspection system to ensure the products meet international standards and satisfy customers. We resolutely put an end to unqualified products flowing into the market. At the same time, we will provide necessary follow-up service assurance. Any problems arising from the cooperation shall be answered within 24 hours and solved within 72 hours.
  • Free samples are available. Specifications can be customized as per your request.
