Product Details:
Payment & Shipping Terms:
|
Features: | Beautiful Appearance, High Tensile Strength, Add More Security, Etc. | Product Name: | 12/14/16 Hot-Dipped Galvanized Barbed Wire For Prison Security Fence |
---|---|---|---|
Material: | Galvanized Iron Wire; PVC Coated Iron Wire In Green, Blue, Gray And Any Other Colors | Wire Diameter: | 12,14,16 Gauge |
Barb Length: | 1.5-3cm | Barb Spacing: | 7.5-15cm |
Zinc Coating: | 30-200g/sqm | Waeving Type: | Normal Twist, Reverse Twist |
Coil Length: | 100m, 150m, 200m, 250m, 500m, Etc. | Coil Weight: | 8kg, 10kg, 15kg, 20kg, 25kg/coil |
Color: | Silver/Galvanized, Dark Green, Gray, Or As Per Your Request | Packaging: | In Bulk; On Wooden Pallet |
Anping HUILONG began to engage in the wire mesh production industry from 1986, so far it has been 35 years. Making wire mesh products widely used in all walks of life has always been the power and direction of our development and research.
This is 4 Point Barbed Wire. Metal Material and Sharp Barb! Please handle carefully with gloves. High Tensile Light Duty 16 Gauge makes it easier to manage and bend into shapes. BUT it's still Barbed Wire. This is Not light weight and malleable like copper or other craft wires. It may help to deter pests. Good also for Fencing, Containment, Deterrent, Protection, Division.
In general, prison environments require a high level of security, so Barbed Wire and Concertina Barbed Wire are ideal protection devices. They can be used alone or in combination to increase safety. Also, they are easy to install and economic, making them a great choice.
SPECIFICATIONS
GALVANIZED BARBED WIRE | ||||
Line Wire and Barb Wire Diameter (BWG) |
Approximate Length per Kilogram in meter | |||
Barbs Spacing 3'' | Barbs Spacing 4'' | Barbs Spacing 5'' | Barbs Spacing 6'' | |
12 x 12 | 6.0617 | 6.7590 | 7.2700 | 7.6376 |
12 x 14 | 7.3335 | 7.9051 | 8.3015 | 8.5741 |
12.5 x 12.5 | 6.9223 | 7.7190 | 8.3022 | 8.7221 |
12.5 x 14 | 8.1096 | 8.8140 | 9.2242 | 9.5620 |
13 x 13 | 7.9808 | 8.8990 | 9.5721 | 10.0553 |
13 x 14 | 8.8448 | 9.6899 | 10.2923 | 10.7146 |
13.5 x 14 | 9.6079 | 10.6134 | 11.4705 | 11.8553 |
14 x 14 | 10.4569 | 11.6590 | 12.5423 | 13.1752 |
14.5 x 14.5 | 11.9875 | 13.3671 | 14.3781 | 15.1034 |
15 x 15 | 13.8927 | 15.4942 | 16.6666 | 17.5070 |
15.5 x 15.5 | 15.3491 | 17.1144 | 18.4060 | 19.3386 |
FEATURES
High security
Long service life
Good rust-resistance ability
Anti-climbing and anti-theft
MASS PRODUCTION PROCEDURE
Producing Galvanized Barbed Wire is relatively simple. It is produced by an automatic machine, through which the line wire and the barb wire are twisted together and then rolled into a coil. See the pictures below. The speed of the machine is fast, so the production capacity is also excellent.
1) Raw Material Preparation----High quality galvanized iron wire
2) Machine Weaving or twisting
3) PVC Coating (Color as per requirements)
4) Packaging
5) Container Loading
PACKAGING DETAILS
Barbed Wire is usually made into coils. For container loading, we have bulk loading and wooden pallet loading. Our packaging will ensure the Barbed Wire not being damaged during storage and shipment. According to the customer’s instruction, we will also put the label paper into the packaging. There will be a certain product description on the label paper, representing product specifications, so that you can be clear about the product information. If you have other special requirements, for example your own label, we can also customize the packaging according to your requirements. In a word, if you have any requirements, please come forward and we will give you the best solution.
APPLICATIONS
Galvanized Barbed Wire is widely used for the separation and protection of the boundary of grassland, railway, highway, prison, private field, etc. It can also be used on the top of other types of fences, such as Chain Link Fence, Welded Wire Mesh Fence, Concertina Barbed Wire, etc., to add security in your private property.
RELATED PRODUCTS
You may also like the following products and accessaries to match your Barbed Wire, and we can also arrange the other goods according to your needs.
