Product Details:
Payment & Shipping Terms:
|
Product Name: | 868 /656 Fence Panel For Outdoor Powder Coated Arch Fence For Garden/Powder Coating Double Welded Wire Fence Panel | Material: | Low Carbon Steel Wire |
---|---|---|---|
Max Height & Width: | 2500mm & 3000mm According To Loading Containers Requirements | Color: | All Colors In RAL Standard Colors Are Avaliable |
Surface Treatment: | Electro Galvanized, Hot-dipped Galvanized, PVC Coated. | Application: | Fence For Construction, Garden, Farm, Residential Areas, Etc. |
Highlight: | 656 Welded Mesh Fence,868 Double Welded Mesh Fence,Powder Coated 868 mesh fencing |
Security the connection of post&panel adopts special made fixture, connect with stainless steel anti-thief screws, avoid the demolition. Double horizontal wire panel design with high rigidity. Long lifetime the coating technology guarantees a long lifetime.After galvanizing an adhesion coating is applied for a perfect bond with the polyester coating. Fast installation easy to master, convenient and reduce the cost. Complete system the system includes panels in different mesh apertures and heights, posts with adapted fixing systems and a large range of mesh and gates. All components guarantee a fast and professional installation.
Name | Mesh size | Wire thickness | Surface treatment | Panel width | Panel height(m) |
Panel weight (kg) |
Double panel |
50*200mm 55*200mm |
5mm vertical wire, 6mm horizontal wire |
Galvanized and electro static Polyester Powder coated |
2.50 | 0.63 | 9.00 |
0.83 | 11.50 | |||||
1.03 | 14.20 | |||||
1.23 | 16.8 | |||||
1.43 | 19.3 | |||||
1.83 | 21.90 | |||||
1.83 | 24.60 | |||||
2.03 | 27.10 | |||||
2.23 | 29.20 | |||||
2.43 |
31.7 |
Name | Mesh size | Wire thickness | Surface treatment | Panel width | Panel height(m) | Panel weight(kg) |
Double panel |
50*200mm 55*200mm |
6mm vertical wire, 8mm horizontal wire |
Galvanized and electro static Polyester Powder coated |
2.50 | 0.63 | 14.60 |
0.83 | 18.80 | |||||
1.03 | 23.00 | |||||
1.23 | 27.10 | |||||
1.43 | 31.30 | |||||
1.63 | 35.40 | |||||
1.83 | 39.50 | |||||
2.03 | 43.75 | |||||
2.23 | 48.00 | |||||
2.43 | 52.00 |
VARIATIONS FOR POST
The posts are available in a range of lengths to accommodate panel heights and ground conditions.
In addition, many variations are available:
● wall fixing plates, cranked posts or base plated
● cranked or straight extensions for barbed or razor wire
● cranked panels
Size | Wall thickness | Surface treatment | Length | Base plate | Rain hat |
60*40mm |
2.0mm 2.5mm |
Galvanized and Electrostatic Polyester Powder coated |
On the basis of panel height |
available |
Plastic Or metal |
80*40mm |
Size | Wall thickness | Surface treatment | Length | Base plate | Rain hat |
60*40mm |
2.0mm 2.5mm |
Galvanized and Electrostatic Polyester Powder coated |
On the basis of panel height |
available |
Plastic Or metal |
80*40mm |
APPLICATION
PACKAGING
Mesh panels: Metal pallet wrapped with cardboard plate and then wrapped with plastic film
Post: Wrapped with PP bags, then put on pallet, wrapped with plastic film;
QUALITY INSPECTION BEFORE LOADING
Perfect quality control system, can ensure the delivery of goods on time. After completing the mass production, quality inspectors of our factory and the inspectors designated by the customers will check and test the products to ensure that the quality and quantity meet customers’ requirements. Meanwhile, the inspection and loading process will be timely fed back to the customers in the form of documents.
QUALITY CONTROL
HUILONG has always adhered to strict quality control in last 30 years, starting from raw material control to finished products,even packing and loading to container. Three quality inspectorsare responsible for different goods, ensuring that all goods arein good condlition before shipment.160 experienced workers, efficient and advancedmachinery and equipment, keep Huilong’s product quality at a high level always. All thatkeep huilong an more than 1000 containersoutput each year in a stableway.Unlike other factory, we never do shoddy work and use inferior material to compete price with others.HUIL ONG always insist on quality, and we prefer good pricewith good quality for long term business.For the wire mesh and fence coating issue, HUILONG will not lose every step as customers’ request.
AFTER-SALES SERVICE SYSTEM
1) After the order is confirmed, we will update the production schedule of the goods in time.
2) Any problems arising from our cooperation shall be answered within 24 hours and solved within 72 hours.
3) If any quality problem is found before delivery, we will deal with it in time.
4) When the goods arrive at the destination port, the customer finds the problem after unpacking the box. Please take photos and feedback to us. We will solve the problem within 24 hours.
FREQUENTLY ASKED QUESTIONS
Q1: Are you a factory or trading company?
We are a 18-year factory and we have registered trading company for sourcing more valuable products for the customers. Therefore, we have both the advantages of factory and trading company. We have our own factory, so we can control the product quality timely and efficiently. At the same time, we also have a professional international trade team, providing good and professional services for customers.
Q2: What’s the MOQ?
MOQ is 100 pieces for common standardized products and ready stock; For Customized Products, MOQ should be negotiated in advance. There is no MOQ for sample orders.
Q3: How to guarantee the quality of products?
We have established the Department of Quality Assurance, every steps from raw material preparation to final product, we have strict quality inspection system to ensure the products meet international standards and satisfy customers. We resolutely put an end to unqualified products flowing into the market. At the same time, we will provide necessary follow-up service assurance. Any problems arising from the cooperation shall be answered within 24 hours and solved within 72 hours.
