High Quality Galvanized Concertina Barbed Wire With Secure Fence
|
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Features: | Sharp Barbs, High Tensile Strength, Corrosion Resistance | Product Name: | Galvanized Concertina Barbed Wire Secure In Private Area |
|---|---|---|---|
| Material: | Galvanized Steel | Wire Diameter: | 2.0, 2.5, 2.8mm |
| Coil Diamter: | 450mm,500mm | Tensile: | 1400-1500MPA |
| International Standard: | ASTM, EN | Application: | For High Security, Private Garden, Barrier Fence, Etc. |
| Packing: | In Coils Or On Pallets | Keyword: | Anti-Climb Bto22 Razor Barbed Wire |
| Highlight: | High Quality Concertina Barbed Wire,Secure Fence Barbed Wire,Secure Fence Concertina Barbed Wire |
||
High Quality Galvanized Concertina Barbed Wire With Secure Fence
Product Specifications
Product Name
Galvanized Concertina Barbed Wire Secure In Private Area
Material
Galvanized Steel
Wire Diameter
2.0, 2.5, 2.8mm
Coil Diameter
450mm, 500mm
Tensile Strength
1400-1500MPA
International Standard
ASTM, EN
Features
Sharp barbs, high tensile strength, corrosion resistance
Application
High Security, Private Garden, Barrier Fence
Packing
In coils or on pallets
Product Description
Galvanized concertina barbed wire provides a robust perimeter security solution, offering an effective deterrent against unauthorized access. Manufactured from high-tensile steel wire with meticulous galvanization, it delivers exceptional durability and corrosion resistance, making it ideal for demanding outdoor applications.
Raw Materials
Razor Material: Galvanized Steel or Stainless Steel
Razor Thickness: 0.5mm
Barb Length: 12-65mm
Barb Spacing: 26-100mm
Core Wire Material: Electro Galvanized, Hot-dipped Galvanized, or Stainless Steel Wire
Core Wire Diameter: 2.5mm
Product Dimensions
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
|---|---|---|---|---|
| 300mm | 33 | 4-6m | CBT-60, CBT-65 | Single Coil |
| 450mm | 33 | 7-8 m | CBT-60, CBT-65 | Single Coil |
| 500mm | 56 | 12-13m | CBT-60, CBT-65 | Single Coil |
| 700mm | 56 | 13-14m | CBT-60, CBT-65 | Single Coil |
| 960mm | 56 | 14-15m | CBT-60, CBT-65 | Single Coil |
| 450mm | 56 | 8-9m (3 clips) | BTO-10, BTO-22, BTO-30 | Cross Type |
| 500mm | 56 | 9-10m (3 clips) | BTO-10, BTO-22, BTO-30 | Cross Type |
| 600mm | 56 | 10-11m (3 clips) | BTO-10, BTO-22, BTO-30 | Cross Type |
| 700mm | 56 | 10-12m (5 clips) | BTO-10, BTO-22, BTO-30 | Cross Type |
| 800mm | 56 | 11-13m (5 clips) | BTO-10, BTO-22, BTO-30 | Cross Type |
| 900mm | 56 | 12-14m (5 clips) | BTO-10, BTO-22, BTO-30 | Cross Type |
| 980mm | 56 | 14-16m (5 clips) | BTO-10, BTO-22, BTO-30 | Cross Type |
Manufacturing Process
Raw Material: Galvanized Steel or Stainless Steel Plate + Wire
Machine Punching: Forming blade shape from steel sheets
Machine Forming: Combining coil wire with blade plate
Clip Installation: Using clip guns to install C-ring clips
PVC Coating: Available in RAL 6005 Green or other RAL colors
Packaging: Customizable with waterproof paper, woven bags, cartons, or pallets
Packaging Options
Our concertina barbed wire is packaged with special attention to safety and transportation efficiency:
Standard Coil Packaging: Waterproof paper + woven bag
Compressed Packaging: 10-20 coils bound with steel belts
Retail Packaging: Individual coils in small corrugated boxes
Carton Packaging: 3-5 coils per customized carton
Pallet Packaging: Compressed wire with plastic film and packing belts
Production Capacity
Our 5,000 square meter production facility includes 5 punching machines, 20 wire wrapping machines, and 50 automatic pneumatic clip guns. With substantial inventory available, we can promptly deliver standard specification products upon payment confirmation.
Quality Assurance
Our comprehensive quality control system ensures timely delivery of products that meet international standards (ASTM F1910-98, ASTM F1379-95, ASTM F1911-05). Both our inspectors and customer-designated inspectors verify product quality and quantity before shipment.
After-Sales Service
Regular production schedule updates
24-hour response to inquiries
72-hour problem resolution
Immediate handling of pre-delivery quality issues
24-hour response to post-delivery concerns
Frequently Asked Questions
Are you a factory or trading company?
We are an 18-year manufacturing company with our own factory and registered trading company, combining production control with professional international trade services.
What's the MOQ?
Minimum order quantity is 50 coils for standard products. Custom products require negotiation. No MOQ for samples.
How do you guarantee product quality?
Our Quality Assurance Department implements strict inspections at every production stage. We provide 24-hour response and 72-hour resolution for any issues.
Company History
1989: Company established in Anping Wire Mesh World Supermarket
1994: Founded Anping HUILONG wire mesh factory
1998: First international cooperation with Philippines
2004: Became joint venture company with Philippines investment
2008: Expanded to European market
2009: Built new factory in Taicheng industry park
2011: Exported to over 100 countries
2012: Established Shijiazhuang international trade branch
2015: Joined Anping Wire Mesh Chamber of Commerce
2016: Expanded foreign trade team
2020: Established Concertina Razor Wire Factory
2021: Expanded domestic trade operations
